Description:





SKF 21305CC/C3 Spherical Roller Bearing

25 x 62 x 17 mm | Cylindrical Bore | C3 Clearance | Steel Cage | Open Bearing

Product Description

The 21305CC/C3 SKF is a high-quality spherical roller bearing designed to support high radial loads and axial loads in both directions. This bearing has an open design with no seals, making it suitable for applications where external lubrication is used.

It features a cylindrical bore, C3 internal clearance, and a steel cage design. The spherical outer ring raceway allows the bearing to compensate for shaft deflection and misalignment, helping provide reliable operation in demanding machinery.

The CC design includes two window-type steel cages, a flangeless inner ring, and a guide ring centered on the inner ring.

Main Specifications

Specification	Details
Brand	SKF
Item Number	21305CC/C3
Bearing Type	Spherical Roller Bearing
Bore Type	Cylindrical Bore
Inner Diameter	25 mm / 0.9843 in
Outer Diameter	62 mm / 2.4409 in
Width	17 mm / 0.6693 in
Clearance	C3 — Greater than Normal
Cage Type	Steel Cage
Seal	Open Bearing / No Seal
Lubrication Feature	No Lubrication Groove or Holes
Weight	0.27 kg
EAN	7316570452730
Manufacturer Part Number	7316570452730
Customs Tariff Number	8482 3000

Suffix Meaning

Suffix	Meaning
CC	Two window-type steel cages, flangeless inner ring, and guide ring centered on the inner ring
C3	Internal clearance larger than normal

Product Features

• Open spherical roller bearing
• Cylindrical bore
• C3 radial internal clearance
• Steel cage design
• No seals
• No lubrication groove or holes
• Designed to compensate for misalignment and shaft deflection
• Suitable for high radial loads and axial loads in both directions

Applications

Common applications include:

• Elevators
• Textile machinery
• Food processing equipment
• Cranes
• Conveyors
• Industrial machinery
• Gearboxes
• General heavy-duty shaft support applications

















Package Includes: ONE (1) SKF Bearing 21305 CC C3
