Koyo DAC4584W-16CS71 Wheel Bearing 45x84x45 mm BAH-0160A Toyota Lexus Mazda Ford

Item Specifics:
Brand: Koyo / JTEKT
Model / Item Number: DAC4584W-16CS71
Also Known As: BAH-0160A
EAN: 4549250221828
Category: Angular Contact Ball Bearing Double Row
Bearing Type: Double Row Angular Contact Ball Bearing / Wheel Bearing
Bore Type: Cylindrical Bore
Seal Type: Open / No Seal
Cage Type: Steel / Standard Cage
Internal Clearance: Special Internal Clearance
Precision: Standard Precision
Lubrication: Standard Lubrication
Heat Stabilization: No Heat Stabilization, temperatures up to 120°C
Split Ring Design: Split Inner Ring
Country of Origin: Japan
Weight: 0.819 kg approx.

Dimensions:
Inner Diameter: 45 mm / 1.7717"
Outer Diameter: 84 mm / 3.3071"
Width: 45 mm / 1.7717"

Suffix Description:
CS71: Special internal clearance specification

Possible Substitutes / Cross References:
DAC4584W-16CS71
BAH-0160A
510063
DAC 4584 W-11 A CS71
DAC 4584 W-6 CS71
AU0942-4 LXL/L588
GB 35360 S01
GP9A-33-047A
GP9A-33-047B
GP9A-33-047C
GP9A-33-047D
VKBA 3946, bearing only
VKBA 6849, bearing only
P-AU0969-1 LL/L588
DAC4584W-16CS71
90080-36193

Possible Vehicle Fitment:
Toyota Avalon: 2005-2013
Toyota Camry: 2004-2016
Toyota Highlander: 2001-2007
Toyota Sienna: 2004-2010
Toyota Venza: 2009-2010
Toyota Solara: 2004-2008
Toyota Matrix: 2009-2013
Pontiac Vibe: 2009-2010
Lexus ES330: 2004-2006
Lexus ES350: 2007-2013
Lexus RX330: 2004-2006
Lexus RX350: 2007-2009
Lexus RX400h: 2006-2008
Mazda CX-7: 2007-2010
Mazda CX-9: 2007-2010
Mazda 6 Mazdaspeed Sedan AWD: 2006-2007
Ford Edge: 2007-2013
Lincoln MKX: 2007-2013

Description:
This listing is for one Koyo / JTEKT DAC4584W-16CS71 double-row angular contact ball bearing.

The DAC4584W-16CS71, also known as BAH-0160A, is a double-row angular contact ball bearing with a cylindrical bore, steel cage, open design, split inner ring, and special internal clearance. It measures 45 mm inner diameter, 84 mm outside diameter, and 45 mm width.

Double-row angular contact ball bearings are designed to support combined radial and axial loads in both directions. This bearing is commonly used in automotive wheel bearing, hub bearing, drivetrain, and mechanical applications where this exact part number or cross reference is required.

Main Features:

·         Genuine Koyo / JTEKT DAC4584W-16CS71 bearing

·         Also known as BAH-0160A

·         Double-row angular contact ball bearing

·         Wheel bearing / hub bearing application

·         Open design, no seals

·         Cylindrical bore

·         Steel cage

·         Split inner ring design

·         Special internal clearance

·         45 mm bore size

·         84 mm outside diameter

·         45 mm width

·         Cross references multiple automotive bearing numbers

·         Suitable for Toyota, Lexus, Mazda, Ford, Lincoln, and Pontiac applications listed above

·         Made in Japan

Please verify all dimensions, part number, cross reference, clearance, and vehicle compatibility before purchasing to make sure this item fits your application.

PACKAGE INCLUDES: ONE (1) KOYO Bearing DAC4584W-16CS71
