Koyo Front Wheel Bearing & Seal Kit Ford F-150 2WD 1997-2003

Item Specifics:
Brand: Koyo / JTEKT
Kit Type: Front Wheel Bearing and Seal Kit
Vehicle Application: Ford F-150 2WD Truck
Fitment Years: 1997-2003
Position: Front, Both Sides
Application: Front Wheel Hub / Front Wheel Bearing Service
Bearing Type: Tapered Roller Bearing
Bearing Design: Cone and Race / Cup and Cone Assembly
Seal Type: Flanged Oil Seal
Seal Material: Nitrile
Country of Origin for Bearings: Japan

Kit Includes:
2 pcs JL69349 Koyo Inner Bearing Cones
2 pcs JL69310 Koyo Inner Bearing Races / Cups
2 pcs LM12749 Koyo Outer Bearing Cones
2 pcs LM12710 Koyo Outer Bearing Races / Cups
2 pcs 4148 Oil Seals

This kit services both front wheels, driver side and passenger side.

Inner Bearing Specifications:
Brand: Koyo / JTEKT
Model / Item Number: JL69349/10
Also Known As: JL69349/310 / SET11
EAN: 605790124969
Category: Tapered Roller Bearing Single Row
Product Type: Complete Cone and Cup Assembly
Precision: Standard Precision
Weight: 0.22 kg approx.

Inner Bearing Dimensions:
Inner Diameter: 38 mm / 1.4961"
Outer Diameter: 63 mm / 2.4803"
Width: 17 mm / 0.6693"

Outer Bearing Specifications:
Brand: Koyo / JTEKT
Model / Item Number: LM12749/10
Also Known As: HI-CAP LM12749/10 / HI-CAP LM12749/LM12710 / LM12749/710 / LM12749/LM12710
Category: Tapered Roller Bearing Single Row
Product Type: Complete Cone and Cup Assembly
Precision: Standard Precision
Weight: 0.12 kg approx.

Outer Bearing Dimensions:
Outer Diameter: 45.24 mm / 1.781"
Width: 15.49 mm / 0.61"

Seal Specifications:
Seal Number: 4148
Series: 4000
Category: Oil Seal / Shaft Seal
Seal Type: Flanged Oil Seal
Material: Nitrile
Measurement System: Inch
Application Type: Automotive Shaft Seal

Seal Dimensions:
Shaft Size / Inner Diameter: 2" / 50.8 mm
Outer Diameter: 2.627" / 66.726 mm
Flanged Outside Diameter: 2.865" / 72.771 mm
Housing Bore: 2.623" / 66.624 mm
Overall Width: 0.28" / 7.112 mm

Vehicle Fitment:
Ford F-150 2WD Truck: 1997-2003

Description:
This listing is for one complete front wheel bearing and seal kit for Ford F-150 2WD trucks from 1997 to 2003.

This kit includes the inner bearings with races, outer bearings with races, and oil seals required to service both front wheels. The kit includes components for the driver side and passenger side.

The inner and outer wheel bearings are Koyo / JTEKT tapered roller bearings. Tapered roller bearings are designed to handle combined radial and axial loads, making them ideal for automotive wheel hub applications.

The included oil seals are nitrile flanged shaft seals designed to help retain lubricant and protect the wheel bearing area from dirt, moisture, and contaminants.

Main Features:

·         Complete front wheel bearing and seal kit

·         Fits Ford F-150 2WD trucks from 1997-2003

·         Services both front wheels

·         Includes driver side and passenger side components

·         Includes 2 inner bearing cones

·         Includes 2 inner bearing races / cups

·         Includes 2 outer bearing cones

·         Includes 2 outer bearing races / cups

·         Includes 2 oil seals

·         Koyo / JTEKT tapered roller bearings

·         Inner bearing set: JL69349 / JL69310

·         Outer bearing set: LM12749 / LM12710

·         Seal number: 4148

·         Designed for front wheel hub service

·         Suitable for automotive wheel bearing replacement

·         Bearings made in Japan

• Compatibility: Fits a range of models including:
• Ford F-150 (1997-2003)
• Ford Expedition (1997-2002)
• Ford F-250 (1997-1999)
• Ford F-150 Heritage (2004)
• Lincoln Navigator (1998-2002)
• Lincoln Blackwood (2002)

Please verify all part numbers, dimensions, bearing numbers, seal dimensions, and vehicle compatibility before purchasing to make sure this kit fits your application.
