Brand: SKF
Part Number: NK22/20
Alternate Part Numbers: NB223020, NK22/20-XL, RNA223020, TAF223020
EAN: 7316577118066
Manufacturer Part Number: 7316577118066
Category: Needle Roller and Cage Assembly
Product ID: 10226536
Country of Origin: Slovakia
Customs Tariff Number: 8482 4000

Inner Diameter (d): 22 mm / 0.8661 in
Outer Diameter (D): 30 mm / 1.1811 in
Width (B): 20 mm / 0.7874 in
Weight: 0.037 kg

Bearing Type: Machined Needle Roller Bearing
Needle Rows: Single Row
Inner Ring: Without Inner Ring
Seal Type: Open / No Seal
Radial Clearance: Normal Radial Clearance
Cage Type: Sheet Steel Cage
Lubrication Feature: Groove with Lubrication Hole(s)
Tolerance Class: P0 / PN / ABEC 1
Operating Temperature Range: -20 °C to +100 °C

Description:
The SKF NK22/20 is a single-row machined needle roller bearing with an open design and no inner ring. It is built with a sheet steel cage and features lubrication groove with hole(s) for improved grease or oil supply. This bearing is designed for applications requiring high radial load capacity in a compact space, especially where the shaft can serve directly as the raceway.

   PACKAGE INCLUDES: ONE (1) SKF Bearing NK22/20
