Brand: SKF
Part Number: 6004-2RZTN9/C3VT162

Also Known As: 6004-2RZTN9/C3

Category: Deep Groove Ball Bearing, Single Row
Bearing Type: Single Row Deep Groove Ball Bearing
Bore Type: Cylindrical Bore
Seal Type: 2RZ, Non-Contact Seals on Both Sides
Cage Type: TN9, Glass Fiber Reinforced Polyamide 6,6 Cage
Internal Clearance: C3
Precision: Standard Precision
Lubrication: VT162 Grease
Heat Stabilization: Up to 120 °C
Material: Standard Bearing Steel
Rolling Elements Material: Standard Bearing Steel

Inner Diameter (d): 20.000 mm
Outer Diameter (D): 42.000 mm
Width (B): 12.000 mm

Inner Diameter (d) Inch: 0.7874 in
Outer Diameter (D) Inch: 1.6535 in
Width (B) Inch: 0.4724 in

Weight: 0.0684 kg

Temperature Range: -40 °C to +120 °C
Tolerance Class: P0 / PN2 / ABEC 1
Outer Ring: Without Flange/Groove
Current Insulation: No Current Insulation
Country of Origin: Germany
Customs Tariff Number: 8482 1090
EAN: 7316570676815
Manufacturer Part Number: 7316570676815
Product ID: 10250838

Suffix Meaning:
2RZ: Low-friction seal on both sides, consisting of sheet steel washer with vulcanized rubber
TN9: Injection-molded snap-type cage of glass fiber reinforced polyamide 6,6, ball-centered
C3: Internal clearance greater than normal
VT162: Special lubrication designation

Description:
The SKF 6004-2RZTN9/C3VT162 is a single-row deep groove ball bearing with non-contact low-friction seals on both sides, designed for smooth running, reduced contamination ingress, and reliable operation at higher speeds.

This bearing features a TN9 polyamide cage, C3 internal clearance, and VT162 lubrication, making it suitable for applications where slightly increased internal clearance and consistent grease performance are required. It can support radial loads and light axial loads in both directions, and is commonly used in electric motors, pumps, gearboxes, fans, and general industrial machinery.

   PACKAGE INCLUDES: ONE (1) SKF Bearing 6004 2RZ TN9/C3 VT162
