Brand: NTN
Part Number: 4T-HM89449
Category: Cone for Tapered Roller Bearings, Single Row

Inner Diameter (d): 36.51 mm / 1.4375 in
Width (B): 28.58 mm / 1.1250 in
Weight: 0.397 kg

Bearing Type: Tapered Roller Bearing Cone
Product Range: Inner Ring (Cone) Only, with Roller Set
Row Design: Single Row
Material: Case-Hardened Steel
Cage: Sheet Steel Cage
Precision Rating: P0 / PN2 / ABEC 1
Arrangement: Standard Version
Temperature Range: -40 °C to +120 °C
Country of Origin: Japan
EAN: 4547359476415
Customs Tariff Number: 8482 2000
Product ID: 10128790

Description: NTN 4T-HM89449 is a cone for a single-row tapered roller bearing. This component includes the inner ring and roller set and must be paired with the matching cup from the same manufacturer to form a complete bearing assembly. The tapered geometry allows the bearing to support combined radial and axial loads in one direction. Its separable design also makes mounting, dismounting, and preload or end-play adjustment easier during installation.

Recommended Use: Always use with the matching NTN cup to ensure proper internal geometry, load distribution, and service life.

   PACKAGE INCLUDES: ONE (1) NTN Bearing HM89449
