Brand: NSK
Part Number: 3210B-2ZRTNG
EAN: 00029176421990
Category: Angular Contact Ball Bearing, Double Row
Product ID: 10096353
Country of Origin: Germany
Customs Tariff Number: 8482 1090

Inner Diameter (d): 50 mm / 1.9685 in
Outer Diameter (D): 90 mm / 3.5433 in
Width (B): 30.2 mm / 1.189 in
Weight: 0.677 kg

Bearing Type: Double Row Angular Contact Ball Bearing
Bore Type: Cylindrical Bore
Seal Type: Metal Shields on Both Sides
Cage Type: Polyamide Cage
Cage Design: Solid Glass-Fiber Reinforced Polyamide Cage, Ball Riding
Contact Angle: 25°
Radial Internal Clearance: CN / Normal Internal Play
Precision: Standard Precision
Tolerance Class: P0 / PN / ABEC 1
Lubrication: Standard Lubrication
Heat Stabilization: None - Up to 120 °C
Split Inner Ring / Outer Ring: Standard
Operating Temperature Range: -20 °C to +120 °C
Outer Ring: Without Flange / Groove
Material: Standard Bearing Steel

Suffix Meaning:
B: 25° contact angle
2ZR: Metal shields on both sides
TNG: Solid glass-fiber reinforced polyamide cage, ball riding

Description:
NSK 3210B-2ZRTNG is a double row angular contact ball bearing with metal shields on both sides and a 25° contact angle. It features a glass-fiber reinforced polyamide cage, standard precision, and normal radial internal clearance. This bearing is designed to support combined radial and axial loads and is suitable for applications requiring a compact double row angular contact design.

   PACKAGE INCLUDES: ONE (1) NSK Bearing 3210B 2ZR TNG
