BRAND: KOYO

ID: JM205149 JM205110

MADE IN: JAPAN

Description:

• Item NumberJM205149/JM205110

• Also known asJM205149/110

JM205149-99401

SET315

• Category Tapered Roller Bearing Single Row

Weight and Dimensions

• Inner (d) MM50

• Outer (D) MM90

• Width (B) MM28

• Inner (d) Inch1.9685

• Outer (D) Inch3.5433

• Width (B) Inch1.1024

• Weight (kg)0.74

Product Properties

• Precision Standard Precision

• Product description

• The JM205149/JM205110 Koyo is a single-row tapered roller bearing. This bearing type gets its name from the tapered rollers between the inner and outer rings. The raceways are conical. This design allows these versatile bearings to accommodate combined loads. They support high radial and axial loads (in one direction). The greater the contact angle, the greater the axial load capacity.

• The JM205149/JM205110 Koyo is easy to (dis)assemble as it is a combination of a cup and a cone. The cone unit consists of an inner ring with cage and roller set. The cup is the outer ring. Single-row tapered roller bearings have an open design. Because of the internal construction, they must be mounted in mirror-image arrangement together with a second tapered roller bearing. Paired bearing sets can also be applied in X, O, or tandem arrangements.
