Brand: Koyo (JTEKT)
Part Number: JHM516849/10
Alternate Part Numbers: JHM516849/810, JHM516849/JHM516810, JHM516849-99401
Category: Tapered Roller Bearing, Single Row
Country of Origin: Japan
EAN: 4549250021053
Customs Tariff Number: 8482 2000
Product ID: 10307463

Inner Diameter (d): 85 mm / 3.3465 in
Outer Diameter (D): 140 mm / 5.5118 in
Width (B): 39 mm / 1.5354 in
Weight: 2.29 kg

Bearing Type: Single Row Tapered Roller Bearing
Design: Complete Tapered Roller Bearing
Construction: Cup and Cone Design
Precision: Standard Precision
Material: Standard Bearing Steel
Cage Type: Sheet Steel Cage
Roller Rows: Single Row
Arrangement: Standard Version
Version: Increased Capacity
Seal Type: Open Design
Load Type: Combined Radial and Axial Loads
Axial Load Direction: One Direction
Tolerance Class: P0 / PN / ABEC 1
Temperature Range: -30 °C to +120 °C

Mounting Notes: Must be mounted in mirror-image arrangement with a second tapered roller bearing; paired sets can also be used in X, O, or tandem arrangements.

Description: The Koyo (JTEKT) JHM516849/10 is a single-row tapered roller bearing designed for high radial and axial loads in one direction. Its conical raceways and tapered rollers allow it to handle combined loads efficiently. The bearing consists of a cone unit with inner ring, cage, and roller set, plus a cup as the outer ring. Its separable design makes installation and disassembly easier.

   PACKAGE INCLUDES: ONE (1) KOYO Bearing JHM516849/10
