Description:





KBS 7004C Angular Contact Ball Bearing Single Row 15° Contact Angle 20x42x12 mm

Item Specifics:
Brand: KBS
Model / Item Number: 7004C
Category: Angular Contact Ball Bearing Single Row
Bearing Type: Single Row Angular Contact Ball Bearing
Seal Type: Open / No Seal
Cage Type: Plastic Molded Cage
Contact Angle: 15°
Pairing: No Pairing
Axial Internal Clearance / Preload: No Preload
Precision: Standard Precision
Lubrication: Standard Lubrication
Weight: 0.069 kg approx.

Dimensions:
Inner Diameter: 20 mm / 0.7874"
Outer Diameter: 42 mm / 1.6535"
Width: 12 mm / 0.4724"

Suffix Description:
C: 15° contact angle

Description:
This listing is for one KBS 7004C single-row angular contact ball bearing.

The 7004C is an open angular contact bearing with no seals, a plastic molded cage, and a 15° contact angle. Angular contact ball bearings are designed to support combined loads, meaning they can handle radial loads together with axial loads in one direction.

This bearing is supplied as a single bearing with no pairing and no preload. It is suitable for industrial, mechanical, spindle, motor, and precision machinery applications where an angular contact bearing with a 15° contact angle is required.

Main Features:

·         Genuine KBS 7004C bearing

·         Single-row angular contact ball bearing

·         Open bearing, no seals

·         15° contact angle

·         Plastic molded cage

·         No preload

·         No pairing

·         20 mm bore size

·         42 mm outside diameter

·         12 mm width

·         Standard precision

·         Standard lubrication

·         Suitable for combined radial and axial load applications

Please verify all dimensions, part number, contact angle, preload, and specifications before purchasing to make sure this item fits your application.





   PACKAGE INCLUDES: ONE (1) KBS Bearing 7004C
