Description:

Brand: INA
Part Number: NK70/35-XL
Manufacturer Part Number: 0507545990000
Also Known As: NB708535, NK70/35, RNA708535, TAF708535
EAN: 4012802566352
Category: Needle Roller Bearing
Series: NK Light Series
Product ID: 10210018
Country of Origin: Slovakia
Customs Tariff Number: 8482 4000

Inner Diameter (d): 70 mm
Outer Diameter (D): 85 mm
Width (B): 35 mm

Inner Diameter (d): 2.7559 in
Outer Diameter (D): 3.3465 in
Width (B): 1.378 in

Weight: 0.382 kg

Bearing Type: Machined Needle Roller Bearing
Needle Rows: Single Row
Seal Type: Open / No Seal
Radial Clearance: Normal
Cage Type: Sheet Steel Cage
Inner Ring: Without Inner Ring
Lubrication: Groove with Lubrication Hole(s)
Tolerance Class: P0 / PN / ABEC 1
Temperature Range: -20 °C to +100 °C

Radial Dynamic Load Rating (Cr): 71000 N
Radial Static Load Rating (C0r): 144000 N
Limiting Speed: 6600 rpm
Reference Speed: 4300 rpm
Under Roller Diameter (Fw): 70 mm

Suffix Meaning: XL = X-Life

ECLASS Number: 23-05-09-07
ECLASS2 Number: 23-05-09-07











   PACKAGE INCLUDES: ONE (1) INA Bearing NK70/35 XL
