BRAND: FAG

ID: WS22218 E1 XL 2VSR H40 C4

MADE IN: GERMANY

DESCRIPTION:

EAN4054364637521
• Category Spherical Roller Bearing
Weight and Dimensions
• Weight (kg)3.7
Product Properties
• Bore C - Cylindrical Bore
• Lubrication Enhancement W - No Lubrication Groove or Holes
• Seal2RS2 - Fluro Rubber Seals / High Temperature
• Cage Type S - Steel or Standard Cage
• Radial Internal PlayC4 Internal Play (Higher than C3)
• Precision Standard Precision
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Vibrating Screen Execution Non Vibrating Screen Execution
Data from Schaeffler (medias)
• Width (b) mm48,00
• Basic static load rating, radial (C 0r)"375000.0000"
• Limiting speed (n G)"1300.0000"
Suffix description
• E1Increased Capacity Design
• XLX-Life
• 2VSRSheet Steel Reinforced Rubbing Seals Of Fluro Rubber (FPM) At Both Sides Of The Bearing. Grease Fill 70 To 100% With A Polyurea High Temperature Grease. Annular Groove And Three Lubricating Holes In The Outer Ring
• H40Bearings Without Lubricating Groove And Holes; H40 Replaces Z26, Completely Closed Outer Ring
• C4Bearing Internal Clearance Greater Than C3

PACKAGE INCLUDES: ONE FAG WS22218 E1 XL 2VSR H40 C4
