FAG 30212-XL-P5 Single Row Tapered Roller Bearing – Made in Hungary

Brand: FAG
Item Number: 30212-XL-P5 FAG
Also Known As: 30212-P5
Manufacturer Part Number: 0862734340000 / 086273434-0000
EAN: 4054364842031
Category: Single Row Tapered Roller Bearing
Country of Origin: Hungary

Dimensions:
Inner Diameter: 60 mm / 2.3622 in
Outer Diameter: 110 mm / 4.3307 in
Width: 23.75 mm / 0.9350 in
Inner Ring Width: 22 mm
Weight: 0.95 kg

Product Properties:
Bearing Type: Single Row Tapered Roller Bearing
Design: XL / X-life Design
Precision: P5 Precision – Dimensional and running accuracy to ISO tolerance class 5
Temperature Range: -30°C to +120°C
Arrangement: Standard Version
Product Range: Complete Tapered Roller Bearing

Performance Data:
Basic Static Load Rating: 123,000 N
Limiting Speed: 8,200 rpm
Thermal Speed Rating: 4,250 rpm

Suffix Description:
XL: X-life design
P5: Dimensional and running accuracy to ISO tolerance class 5

Product Description:
The FAG 30212-XL-P5 is a single-row tapered roller bearing designed to support combined radial and axial loads. This bearing consists of a cone and cup assembly. The cone includes the inner ring, cage, and roller set, while the cup is the outer ring.

This bearing has an open design and is commonly used in applications requiring high radial load capacity and axial load support in one direction. Because of its internal construction, single-row tapered roller bearings are typically mounted in pairs or in combination with another tapered roller bearing.

The XL / X-life design provides improved performance compared to standard bearings. X-life bearings offer higher load capacity, longer service life, reduced heat generation, and the ability to operate at higher speeds.

   PACKAGE INCLUDES: ONE (1) FAG Bearing 30212 XL P5
