Description:





FAG 22218-E1A-XL-M-C3 Spherical Roller Bearing

90 x 160 x 40 mm | Cylindrical Bore | C3 Clearance | Brass Cage | Made in Germany

Product Description

The 22218-E1A-XL-M-C3 FAG is a high-quality spherical roller bearing designed for heavy-duty applications requiring high radial load capacity and the ability to handle axial loads in both directions.

This bearing features a cylindrical bore, C3 internal clearance, and a solid brass cage guided by rollers. The outer ring includes a lubrication groove and three lubrication holes, allowing easier relubrication and improved bearing maintenance.

The spherical raceway design allows the bearing to compensate for shaft deflection and misalignment, making it suitable for demanding industrial applications such as cranes, elevators, textile machinery, food processing equipment, conveyors, and heavy machinery.

This bearing is part of FAG’s X-Life series, which provides improved performance, higher load capacity, reduced friction, lower operating temperature, and longer service life compared to standard spherical roller bearings.

Main Specifications

Specification	Details
Brand	FAG
Item Number	22218-E1A-XL-M-C3
Also Known As	22218-E1A-M-C3
Bearing Type	Spherical Roller Bearing
Bore Type	Cylindrical Bore
Inner Diameter	90 mm / 3.5433 in
Outer Diameter	160 mm / 6.2992 in
Width	40 mm / 1.5748 in
Clearance	C3 — Greater than Normal
Cage Type	Solid Brass Cage
Seal	Open Bearing / No Seal
Lubrication Feature	W33 — Lubrication Groove and 3 Holes
Dynamic Load Rating	345,000 N
Static Load Rating	375,000 N
Limiting Speed	5,200 rpm
Reference Speed	3,400 rpm
Weight	3.35 kg
Country of Origin	Germany
EAN	4026677850454
Manufacturer Part Number	0190169560030
Customs Tariff Number	8482 3000

Suffix Meaning

Suffix	Meaning
E1	Increased Capacity Design
A	Modified Internal Construction
XL	FAG X-Life Premium Performance Design
M	Solid Brass Cage, Roller Guided
C3	Internal Clearance Larger Than Normal
W33	Lubrication Groove and 3 Holes

Applications

Common applications include:

• Heavy-duty industrial machinery
• Cranes and lifting equipment
• Conveyors
• Elevators
• Textile machinery
• Food processing equipment
• Gearboxes
• Mining and aggregate equipment









Package Includes: ONE (1) FAG Bearing 22218 E1 A XL M C3
