Description:





•

   FAG 22218-E1A-XL-K-M-C3 Spherical Roller Bearing

  90 x 160 x 40 mm | Tapered Bore 1:12 | C3 Clearance | Brass Cage | Open Bearing

  Product Description

  The 22218-E1A-XL-K-M-C3 FAG is a premium spherical roller bearing designed for demanding industrial applications requiring high radial load capacity and the ability to support axial loads in both directions.

  This bearing features a 1:12 tapered bore, C3 internal clearance, and a solid brass cage guided by rollers. The outer ring includes a lubrication groove and three lubrication holes, allowing easier relubrication and improved maintenance.

  The spherical raceway design allows the bearing to compensate for shaft deflection and misalignment, making it suitable for heavy-duty applications such as cranes, elevators, textile machinery, food processing equipment, conveyors, gearboxes, and industrial machinery.

  This bearing is part of FAG’s X-Life series, which provides improved performance, higher load capacity, reduced friction, lower operating temperature, and longer service life compared to standard spherical roller bearings.

  Main Specifications

  Specification	Details
  Brand	FAG
  Item Number	22218-E1A-XL-K-M-C3
  Also Known As	22218-E1A-K-M-C3
  Bearing Type	Spherical Roller Bearing
  Bore Type	Tapered Bore 1:12
  Inner Diameter	90 mm / 3.5433 in
  Outer Diameter	160 mm / 6.2992 in
  Width	40 mm / 1.5748 in
  Clearance	C3 — Greater than Normal
  Cage Type	Solid Brass Cage
  Seal	Open Bearing / No Seal
  Lubrication Feature	W33 — Lubrication Groove and 3 Holes
  Dynamic Load Rating	345,000 N
  Static Load Rating	375,000 N
  Limiting Speed	5,200 rpm
  Reference Speed	3,400 rpm
  Weight	3.2 kg
  EAN	4026677850478
  Manufacturer Part Number	0190169990030

  Suffix Meaning

  Suffix	Meaning
  E1	Increased Capacity Design
  A	Modified Internal Construction
  XL	FAG X-Life Premium Performance Design
  K	Tapered Bore, Taper 1:12
  M	Solid Brass Cage, Roller Guided
  C3	Internal Clearance Larger Than Normal
  W33	Lubrication Groove and 3 Holes

  Applications

  Common applications include:

  • Heavy-duty industrial machinery
  • Cranes and lifting equipment
  • Conveyors
  • Elevators
  • Textile machinery
  • Food processing equipment
  • Gearboxes
  • Mining and aggregate equipment



Package Includes: ONE (1) FAG Bearing 22218 E1 A XL KM C3
