Description:





ZEN BA6 Single Direction Thrust Ball Bearing 6x14x5 mm

Item Specifics:
Brand: ZEN
Model / Item Number: BA6
Manufacturer Part Number: BA6
Category: Axial Deep Groove Ball Bearing
Bearing Type: Single Direction Thrust Ball Bearing
Product Range: Axial Deep Groove Ball Bearing
Operating Direction: Single Direction Bearing
Angular Adjustment: Non-Angle Adjustable
Material: Standard Bearing Steel
Rolling Element Material: Standard Bearing Steel
Cage Type: Sheet Steel Cage
Tolerance Class: P0 / PN2 / ABEC 1
Measurement Unit: Metric
Temperature Range: -30°C to +150°C
Customs Tariff Number: 8482 1010
EAN: Not Available
UOM: Each
Weight: 0.005 kg approx.

Dimensions:
Inner Diameter: 6 mm
Outer Diameter: 13.8 mm / 14 mm nominal
Width: 5 mm

Load & Speed Ratings:
Dynamic Load Rating: 1.78 kN
Static Load Rating: 1.92 kN
Fatigue Load Limit Pu: 0.071 kN
Limiting Speed: 24,000 r/min
Reference Speed: 17,000 r/min

Description:
This listing is for one ZEN BA6 axial deep groove ball bearing.

The BA6 is a single direction thrust ball bearing designed to support axial loads in one direction. It is made from standard bearing steel and features a sheet steel cage with standard precision tolerance.

Axial deep groove ball bearings, also known as thrust ball bearings, are commonly used in light-duty mechanical assemblies where axial load support is required and radial load support is not the main function.

This bearing has a 6 mm inner diameter, approximately 14 mm outside diameter, and 5 mm width.

Main Features:

·         Genuine ZEN BA6 bearing

·         Single direction thrust ball bearing

·         Axial deep groove ball bearing design

·         Supports axial load in one direction

·         Standard bearing steel construction

·         Sheet steel cage

·         P0 / PN2 / ABEC 1 tolerance class

·         6 mm inner diameter

·         13.8 mm / 14 mm nominal outer diameter

·         5 mm width

·         Dynamic load rating: 1.78 kN

·         Static load rating: 1.92 kN

·         Fatigue load limit: 0.071 kN

·         Limiting speed: 24,000 r/min

·         Reference speed: 17,000 r/min

·         Compact bearing design

·         Suitable for mechanical, hobby, precision, and light-duty axial load applications

Please verify all dimensions, part number, bearing type, operating direction, load rating, speed rating, and application requirements before purchasing to make sure this item fits your application.







 PACKAGE INCLUDES: ONE (1) ZEN Bearing BA6
