Description:



Timken 33214 Single Row Tapered Roller Bearing – 70 x 125 x 41 mm

Brand: Timken
Item Number: 33214 Timken
Also Known As: 33214-90KA1, 33214-90KA4, 33214-9X025, 33214CM-90KM1
Category: Tapered Roller Bearing Single Row

Dimensions:

·         Inner Diameter (d): 70 mm / 2.7559 in

·         Outer Diameter (D): 125 mm / 4.9213 in

·         Width (B): 41 mm / 1.6142 in

·         Weight: 2.13 kg

Product Features:

·         Bearing Type: Single row tapered roller bearing

·         Precision: Standard precision

·         Cage: Sheet steel cage

·         Roller Rows: Single row

·         Arrangement: Standard version

·         Temperature Range: -30°C to +120°C

·         Tolerance Class: P0 / PN2 / ABEC 1

·         Country of Origin: Romania

Product Description:
The Timken 33214 is a single row tapered roller bearing designed to support combined radial and axial loads. This bearing type features tapered rollers positioned between the inner and outer rings, with conical raceways that allow it to handle high radial loads and axial loads in one direction.

The 33214 Timken consists of a cone assembly and a cup. The cone assembly includes the inner ring, cage, and roller set, while the cup is the outer ring. This design makes the bearing easier to assemble and disassemble during installation or maintenance.

Single row tapered roller bearings have an open design and are commonly mounted in a mirror-image arrangement with a second tapered roller bearing. They may also be used in X, O, or tandem arrangements depending on the application requirements.









Package Includes: ONE (1) TIMKEN Bearing 33214
