Timken 1177 Rear Outer Differential Pinion Seal Toyota Lexus 38x74x11mm

Item Specifics:
Brand: Timken
Model / Item Number: 1177
Also Known As: TB1177
Vendor Part Number: 1177
Part Number: TB1177
UPC / Bar Code: 053893834719
Category: Differential Pinion Seal
Part Type: Pinion Seal / Transmission Seal
Part Name: Seal
Application Type: Rear Outer Differential Pinion Seal / Front Outer Differential Pinion Seal / Transmission Extension Housing Seal
Product Line: Timken Differential Pinion Seals
Material: N-Polyacrylate / Acrylates
Unit of Measure: Each
Quantity: Sold Individually
Weight: 0.136 lb approx.

Dimensions:
Shaft Diameter / Inner Diameter: 38 mm approx.
Housing Bore: 74.00 mm / 2.913"
Outside Diameter: 74.17 mm / 2.920"
Width: 11.00 mm / 0.433"

OE / Cross Reference Numbers:
9031138010
9031138028
9031138035
9031138047
9031138079
9031138133
9031138134

Possible Vehicle Fitment:

Lexus LS400: 1990-1992, Rear Outer Differential Pinion Seal
Lexus LX450: 1996-1997, Rear Outer Differential Pinion Seal
Lexus LX450: 1996-1997, Front Outer Differential Pinion Seal
Lexus LX470: 1998-2002, Rear Outer Differential Pinion Seal
Lexus LX470: 1998-2002, Front Outer Differential Pinion Seal

Toyopet Crown: 1958-1963, Rear Outer Differential Pinion Seal
Toyopet Tiara: 1961-1963, Rear Outer Differential Pinion Seal

Toyota 4Runner: 1984-1994, Front Outer Differential Pinion Seal, 4WD
Toyota 4Runner: 1984-2002, Rear Outer Differential Pinion Seal
Toyota Carina: 1971-1973, Automatic Transmission Extension Housing Seal
Toyota Celica: 1971-1974, Automatic Transmission Extension Housing Seal
Toyota Celica: 1979-1986, Rear Outer Differential Pinion Seal
Toyota Corolla: 1984, Rear Outer Differential Pinion Seal
Toyota Corona: 1967-1974, Automatic Transmission Extension Housing Seal
Toyota Corona: 1969-1973, Rear Outer Differential Pinion Seal
Toyota Cressida: 1978-1992, Rear Outer Differential Pinion Seal
Toyota Crown: 1967-1972, Automatic Transmission Extension Housing Seal
Toyota Crown: 1958-1972, Rear Outer Differential Pinion Seal
Toyota Hi-Lux: 1969-1974, Rear Outer Differential Pinion Seal
Toyota Land Cruiser: 1960-2002, Rear Outer Differential Pinion Seal
Toyota Land Cruiser: 1960-2002, Front Outer Differential Pinion Seal
Toyota Mark II: 1972-1976, Automatic Transmission Extension Housing Seal
Toyota Mark II: 1972-1976, Rear Outer Differential Pinion Seal
Toyota Pickup: 1977-1978, Front Outer Differential Pinion Seal
Toyota Pickup: 1979-1994, Front Outer Differential Pinion Seal, 4WD
Toyota Pickup: 1966-1995, Rear Outer Differential Pinion Seal
Toyota Pickup: 1981-1982, Manual Transmission Output Shaft Seal
Toyota Stout: 1965-1968, Rear Outer Differential Pinion Seal
Toyota Supra: 1986-1992, Rear Outer Differential Pinion Seal
Toyota T100: 1993-1994, Front Outer Differential Pinion Seal, 4WD
Toyota Tiara: 1960-1966, Rear Outer Differential Pinion Seal
Toyota Van: 1984-1989, Rear Outer Differential Pinion Seal
Toyota Van Wagon: 1988, Rear Outer Differential Pinion Seal

Description:
This listing is for one Timken 1177 seal.

The Timken 1177 is commonly used as a rear outer differential pinion seal, front outer differential pinion seal, automatic transmission extension housing seal, or manual transmission output shaft seal in select Toyota, Lexus, and Toyopet applications.

This seal is designed to help retain lubricant while preventing dirt, dust, moisture, and other harmful contaminants from entering the sealing area. Timken seals are engineered for reliable performance in automotive driveline, axle, differential, and transmission applications.

The Timken 1177 features a precision machined rubber sealing edge for improved sealing consistency, an extra dust lip to help protect against contaminants, and a bore coating designed to help seal the outside diameter leak path and compensate for minor housing bore imperfections.

The flanged design helps make installation easier and helps reduce the possibility of cocking during installation.

Main Features:

·         Genuine Timken 1177 seal

·         Also known as TB1177

·         Differential pinion seal / transmission seal application

·         Rear outer and front outer applications depending on vehicle

·         Helps retain lubricant

·         Helps keep dirt and contaminants out

·         Precision rubber sealing edge

·         Extra dust lip for added protection

·         Bore coating helps seal minor housing bore imperfections

·         Flanged design for easier installation

·         Approximate size: 38x74x11 mm

·         Housing bore: 74.00 mm / 2.913"

·         Outside diameter: 74.17 mm / 2.920"

·         Width: 11.00 mm / 0.433"

·         Cross references multiple Toyota OE numbers

·         Suitable for select Toyota, Lexus, and Toyopet applications

Please verify all dimensions, part number, OE reference, position, drivetrain, and vehicle compatibility before purchasing to make sure this item fits your application.

PACKAGE INCLUDES: ONE (1) Timken Seal 1177
