SKF YEL208-108-2F Insert Ball Bearing 1-1/2" Bore 38.1x80x56.3mm

Item Specifics:   G1108 KRR B AS2/V
Brand: SKF
Model / Item Number: YEL208-108-2F
Also Known As: YEL 208-108-2F, 1040-1.1/2DECG
EAN: 7316576617133
Manufacturer Part Number: 7316576617133
Category: Bearings for Housings
Bearing Type: Radial Insert Ball Bearing
Bore Type: Cylindrical Bore
Outer Ring: Spherical / Rounded Outer Ring
Inner Ring: Widened Inner Ring on Both Sides
Fixing Method: Eccentric Locking Collar
Seal Type: 2F - Standard Seal for Y-Bearings
Sealing: Double-sided lip seal covered with steel sheet washers and outer flinger shield with corrosion protection
Material: Standard Bearing Steel
Precision: Standard Precision / P0 / PN2 / ABEC 1
Lubrication: Standard Lubrication
Special Treatment: No Special Treatment
Temperature Range: -20°C to +120°C
Country of Origin: Italy
Customs Tariff Number: 8482 1090
Weight: 0.767 kg approx.

Dimensions:
Inner Diameter / Bore: 38.1 mm / 1.5"
Outer Diameter: 80 mm / 3.1496"
Overall Width: 56.3 mm / 2.2165"
Inner Ring Width: 42.8 mm
Outer Ring Width: 21 mm

Load & Speed Ratings:
Dynamic Load Rating: 30,700 N
Static Load Rating: 19,000 N
Limiting Speed: 4,800 rpm

Cross Reference / OE Reference:
Dodge INS-SXR-108
Dodge SXR-108
John Deere AH163595
John Deere JD10020
John Deere JD9201

Suffix Description:
2F: Standard contact seal with additional plain flinger on both sides of the bearing

Description:
This listing is for one SKF YEL208-108-2F insert ball bearing.

The SKF YEL208-108-2F is a radial insert ball bearing designed for use in bearing housings and mounted bearing units. It features a 1-1/2" bore, spherical outer ring, widened inner ring on both sides, eccentric locking collar, and 2F sealing system.

The spherical / rounded outer ring allows the bearing to be used in suitable housings where alignment compensation is required. The double-sided lip seal with steel sheet washers and outer flinger shield helps retain lubricant while protecting the bearing against dirt, dust, moisture, and contamination.

This bearing measures 38.1 mm inner diameter, 80 mm outside diameter, and 56.3 mm overall width. It is commonly used in agricultural equipment, conveyors, industrial machinery, shaft support applications, and mounted bearing assemblies.

Main Features:

·         Genuine SKF YEL208-108-2F bearing

·         Insert ball bearing for housings

·         Made in Italy

·         1-1/2" bore size

·         Spherical / rounded outer ring

·         Widened inner ring on both sides

·         Eccentric locking collar

·         2F standard contact seals

·         Steel sheet washers with outer flinger shields

·         Corrosion protection

·         38.1 mm inner diameter

·         80 mm outside diameter

·         56.3 mm overall width

·         Dynamic load rating: 30,700 N

·         Static load rating: 19,000 N

·         Limiting speed: 4,800 rpm

·         Cross references Dodge and John Deere numbers

·         Suitable for agricultural, conveyor, industrial machinery, and mounted bearing applications

Please verify all dimensions, part number, seal type, locking method, housing compatibility, cross references, and application requirements before purchasing to make sure this item fits your application.

 PACKAGE INCLUDES: ONE (1) SKF Bearing YEL208-108-2F
