Description:





•

  SKF TMHC 110E Hydraulic Puller Kit – 10 Ton Capacity

  Brand: SKF
  Manufacturer: SKF
  Item Number: TMHC 110E
  Category: Hydraulic Puller Kit
  Type: Puller Kit
  Product Line: MaPro

  Specifications

  Capacity: 10 tons
  Stroke: 80 mm
  Shaft Diameter Range: 20–100 mm
  Maximum Arm Length / Reach: 250 mm
  Weight: 15.537 kg

  Kit Includes

  Hydraulic Spindle: TMHS 100 SKF
  Arm-Assembly Stand: 1 piece
  Puller Arms: 3 arms – 65 mm
  Puller Arms: 3 arms – 115 mm
  Separator Set: 1 piece
  Beam: 1 piece
  Main Rods: 2 pieces
  Extension Rods: 2 pieces – 125 mm
  Hydraulic Spindle Extension Pieces: 2 pieces – 50 mm and 100 mm
  Nosepiece with Centre Point: 1 piece

  Product Features

  • Combines a jaw puller and a strong back puller in one versatile kit.
  • Suitable for use in 2-arm or 3-arm configurations.
  • Designed for the safe and efficient dismounting of bearings and other machine components.
  • Hydraulic spindle enables effortless high-force pulling.
  • Self-locking arms help minimize the risk of slippage under load.
  • Spring-loaded centre point supports easy and accurate centering.
  • Includes two hydraulic spindle extension pieces for quick adjustment to the required pulling length.
  • Integrated safety valve helps prevent puller overload.





Package Includes: ONE (1) SKF Hydraulic Puller Kit TMHC110E
