SKF 35X72X12 HMSA10 RG Double Lip Radial Shaft Seal – Nitrile Rubber NBR – 35 x 72 x 12 mm

Brand: SKF
Item Number: 35X72X12HMSA10RG SKF
Manufacturer Part Number: 35X72X12 HMSA10 RG
EAN: 7316572551837
Category: Radial Shaft Seal / Oil Seal
Type: Double Lip Seal
Design: HMSA10
Material: Nitrile Rubber / NBR
Seal Design: Rubber outside diameter with metal reinforcement ring
Auxiliary Lip: Yes
Garter Spring: Yes
Unit System: Metric

Dimensions
Shaft Diameter: 35 mm
Housing Bore Diameter: 72 mm
Seal Width: 12 mm
Size: 35 x 72 x 12 mm
Shaft Diameter Inch: 1.378 in
Housing Bore Diameter Inch: 2.8346 in
Seal Width Inch: 0.4724 in
Weight: 0.041 kg / 0.048 kg

Performance
Maximum Speed: 3,480 rpm
Permissible Circumferential Speed: 6.39 m/s
Operating Temperature Range: -40°C to +100°C
Sealing Material Temperature Range: -30°C to +100°C

Description
SKF HMSA10 radial shaft seals are designed for use between rotating and stationary machine components, or between components in relative motion. This seal features a rubber outside diameter, a conventional elastomer sealing lip, a garter spring, and a non-contacting auxiliary lip to help optimize sealing performance against the shaft, especially in polluted environments.

Suffix Description
HMSA10: Seal with rubber outside diameter, carbon steel reinforcement ring, auxiliary contacting lip, and carbon or stainless steel garter spring
RG: Nitrile rubber sealing material

Interchange / Cross Reference Numbers
Krone: 009363371
