Description:





 UCFC218D1 NTN Flanged Housing and Bearing Assembly



The UCFC218D1 NTN is a complete round flanged housing unit with a 90 mm bore. It includes a matched bearing and cast iron housing, designed for reliable operation, easy installation, and simplified maintenance.

This unit is supplied with a standard double seal for Y-bearings and standard lubrication. The D1 suffix indicates a relube type design. The housing supports and protects the bearing, helping extend service life in industrial applications.

Product Details:

·         Brand: NTN

·         Item Number: UCFC218D1 NTN

·         EAN: 4547359214024

·         Category: Housing and Bearing Assembly / Flanged Housing Unit

·         Material: Cast iron housing with standard bearing steel bearing

·         Country of Origin: Japan

·         Bore Diameter: 90 mm / 3.5433 in

·         Outside Diameter: 265 mm / 10.4331 in

·         Width: 96 mm / 3.7795 in

·         Weight: Approx. 13.28–13.714 kg

·         Seal Type: 2F — Standard double seal for Y-bearings

·         Lubrication: Standard lubrication

·         Temperature Range: -20°C to +120°C

·         Fixing: Threaded pins

·         Shape: Round flange

·         Number of Holes: 4

·         Color: Green

·         Special Treatment: No special treatment

·         Customs Tariff Number: 8483 2000

·         Suffix: D1 — Relube Type

Also known as:
56218 + FC218, FC56218, FC90, FYC90TF, UC218D1 + FC218D1, YAR218-2F + FYC518









Package Includes: ONE (1) NTN Housing and Bearing Assembly UCFC218
