Description:





Koyo NU2217 Cylindrical Roller Bearing Open 85x150x36 mm

Item Specifics:
Brand: Koyo / JTEKT
Model / Item Number: NU2217
EAN: 4549250036927
Category: Cylindrical Roller Bearing Single Row
Bearing Type: Single Row Cylindrical Roller Bearing
Design: NU Design / Floating Bearing
Bore Type: Cylindrical Bore
Seal Type: Open / No Seal
Outer Ring: Without Groove / Lubrication Holes
Cage Type: Sheet Steel Cage
Radial Internal Clearance: CN Normal Internal Clearance
Precision: Standard Precision / P0 / PN2 / ABEC 1
Heat Stabilization: No Heat Stabilization, temperatures up to 120°C
Current Insulation: No Current Insulation
External Modification: No External Modification
Temperature Range: -20°C to +120°C
Country of Origin: Japan
Customs Tariff Number: 8482 5000
Weight: 2.49 kg approx.

Dimensions:
Inner Diameter: 85 mm / 3.3465"
Outer Diameter: 150 mm / 5.9055"
Width: 36 mm / 1.4173"

Design Description:
NU Design: Cylindrical roller bearing with two ribs on the outer ring and no ribs on the inner ring. The inner ring is removable from both sides, making this design suitable as a floating bearing where axial displacement of the shaft relative to the housing is required.

Description:
This listing is for one Koyo / JTEKT NU2217 single row cylindrical roller bearing.

The NU2217 is an open cylindrical roller bearing with a cylindrical bore, sheet steel cage, CN normal internal clearance, and standard precision. Cylindrical roller bearings are designed to support high radial loads and are commonly used in applications requiring strong radial load capacity and reliable shaft support.

The NU design is commonly used as a floating bearing arrangement. It allows axial displacement in both directions between the shaft and housing, while still supporting radial loads.

This bearing measures 85 mm inner diameter, 150 mm outside diameter, and 36 mm width. It is suitable for gearboxes, electric motors, pumps, compressors, industrial machinery, agricultural equipment, and other heavy-duty mechanical applications.

Main Features:

·         Genuine Koyo / JTEKT NU2217 bearing

·         Single row cylindrical roller bearing

·         Made in Japan

·         NU floating bearing design

·         Open bearing, no seals

·         Sheet steel cage

·         CN normal internal clearance

·         Cylindrical bore

·         Standard precision / P0 / ABEC 1

·         85 mm bore size

·         150 mm outside diameter

·         36 mm width

·         Designed for high radial load capacity

·         Inner ring removable from both sides

·         Allows axial displacement in floating bearing applications

·         Suitable for gearboxes, motors, pumps, compressors, and industrial machinery

Please verify all dimensions, part number, bearing design, clearance, and application requirements before purchasing to make sure this item fits your application.







 PACKAGE INCLUDES: ONE (1) KOYO Bearing NU2217
