Brand: INA
ID: LR606 -2RSR

DESCRIPTION
EAN: 4047643159463

*Category: Support Roller*

Weight and Dimensions

*Inner (d) mm: 6*

*Outer (D) mm: 19*

*Width (B) mm: 6*

*Inner (d) inch: 0.2362*

*Outer (D) inch: 0.748*

*Width (B) inch: 0.2362*

*Weight (kg): 0.01*

Product Properties

*Seal: 2RZ - Rubber and Steel Seal*

*Running Surface: Standard*

Suffix Description

*NPP: Ball Bearing, with Low-Friction Seal on Both Sides. The seal comprises a sheet steel washer with vulcanized rubber.*

*U: Crowned Outside Surface*

Product Description

The LR606-NPPU INA is a ball-bearing yoke type track roller, combining low friction with high precision through its rolling elements. These track rollers are engineered for various types of tracks and can endure significant radial loads due to their thick-walled outer ring. They also accommodate axial loads in both directions caused by alignment errors or misalignment. Yoke type track rollers are intended for shaft mounting rather than being fitted into a housing bore, with a flat counter track providing support.

The LR606-NPPU INA features a cage that prevents the rolling elements from making contact with each other, facilitating controlled movement. This design ensures lower friction compared to full complement track rollers, which enables higher rotational speeds and reduces heat generation. Common applications for support rollers include conveyor systems, linear guidance systems, and cam mechanisms.





Package Includes: ONE (1) INA Bearing LR606 2RSR = LR606 NPPU
