INA NX12 Needle Roller Axial Ball Bearing 12x21x18 mm

Item Specifics:
Brand: INA
Model / Item Number: NX12
Manufacturer Part Number: 050778560-0000
EAN: 4012802735703
Category: Needle Roller / Axial Ball Bearing
Bearing Type: Combined Needle Roller and Axial Ball Bearing
Version: Demountable
Operating Direction: Single Direction Bearing
Material: Standard Bearing Steel
Cage Type: Sheet Steel Cage
Seal Type: Open / No Seal
Lubrication: For Oil Lubrication
Tolerance Class: P0 / PN2 / ABEC 1
Temperature Range: -20°C to +120°C
Country of Origin: Slovakia
Customs Tariff Number: 8482 8000
Weight: 0.028 kg approx.

Dimensions:
Inner Diameter: 12 mm / 0.4724"
Outer Diameter: 21 mm / 0.8268"
Width: 18 mm / 0.7087"

Suffix Description:
G2: Standard quality class for needles
/0-10 Micron: Needle sort

Description:
This listing is for one INA NX12 combined needle roller and axial ball bearing.

The NX12 is a compact combined bearing designed to support radial loads through the needle roller section and axial loads in one direction through the axial ball bearing section. This design allows radial and axial load support in a very small installation space.

This bearing is demountable, open with no seals, and designed for oil lubrication. It is commonly used in gearboxes, transmissions, machine tools, pumps, compact machinery, industrial equipment, and mechanical assemblies where both radial and single-direction axial load support are required.

Main Features:

·         Genuine INA NX12 bearing

·         Combined needle roller and axial ball bearing

·         Supports radial loads and axial loads in one direction

·         Compact bearing design

·         Demountable version

·         Open design, no seals

·         Sheet steel cage

·         Designed for oil lubrication

·         12 mm bore size

·         21 mm outside diameter

·         18 mm width

·         Suitable for gearboxes, transmissions, machinery, and industrial applications

·         Made in Slovakia

Please verify all dimensions, part number, lubrication requirement, bearing type, operating direction, and application requirements before purchasing to make sure this item fits your application.

 PACKAGE INCLUDES: ONE (1) INA Bearing NX12
