INA NATV8-PP-A Yoke Type Track Roller Support Roller 8x24x14 mm

Item Specifics:
Brand: INA
Model / Item Number: NATV8-PP-A
Manufacturer Part Number: 0057127500000
EAN: 4012802428155
Category: Support Roller
Bearing Type: Yoke Type Track Roller / Support Roller
Rolling Element Type: Full Complement Needle Roller Set
Seal Type: 2L / PP - Lip Seals on Both Sides
Running Surface: Standard
Axial Guidance: Axial Plain Washers on Both Sides
Mounting Type: Shaft Mounted
ECLASS Number: 23-05-15-01
Quantity Available: 109 pcs
Weight: 0.0425 kg approx.

Dimensions:
Inner Diameter: 8 mm / 0.315"
Outer Diameter: 24 mm / 0.9449"
Width: 14 mm / 0.5512"
Schaeffler Listed Bearing Width: 15 mm

Load & Speed Ratings:
Basic Dynamic Load Rating, Radial: 7,800 N
Basic Static Load Rating, Radial: 11,700 N
Speed with Permanent Grease Lubrication: 2,500 rpm

Suffix Description:
PP: Lip seals on both sides. P-type seals with two zinc-plated sheet steel washers and intermediate NBR sealing part, axially preloaded seal lip. Temperature range: -30°C to +100°C
A: Alteration in internal construction, identical to old notation

Description:
This listing is for one INA NATV8-PP-A yoke type track roller / support roller.

The NATV8-PP-A is a full complement needle roller track roller designed for high radial load capacity in a compact design. It features a thick-walled outer ring, needle roller set, axial guidance, axial plain washers on both sides, and lip seals on both sides.

Yoke type track rollers are designed to be mounted on a shaft and run directly on a flat or profiled track. They are commonly used in conveyor systems, linear guidance systems, cam mechanisms, automation equipment, material handling equipment, packaging machinery, and industrial machinery.

The full complement design allows a greater number of rolling elements, increasing radial load capacity and shock resistance compared with caged versions. However, full complement track rollers generally have a lower maximum speed than caged track rollers.

Main Features:

·         Genuine INA NATV8-PP-A support roller

·         Yoke type track roller

·         Full complement needle roller design

·         High radial load capacity

·         Thick-walled outer ring

·         Lip seals on both sides

·         Axial guidance with plain washers on both sides

·         Shaft-mounted design

·         Standard running surface

·         8 mm bore size

·         24 mm outside diameter

·         14 mm listed width

·         Dynamic load rating: 7,800 N

·         Static load rating: 11,700 N

·         Suitable for conveyors, cam mechanisms, linear guidance, and industrial machinery

Please verify all dimensions, part number, roller design, seal type, load rating, and application requirements before purchasing to make sure this item fits your application.







 PACKAGE INCLUDES: ONE (1) INA Bearing NATV8 PP A
