Description:





FYH NA208-24 Insert Ball Bearing 1-1/2" Bore  YEL208-108-2F 38.1x80x56.3 mm

Item Specifics:
Brand: FYH
Model / Item Number: NA208-24
Also Known As: G1108-KRR-B / G1108-KRR-B-AS2/V / YEL208-108-2F
Category: Bearings for Housings
Bearing Type: Insert Ball Bearing / Mounted Bearing Insert
Bore Size: 1-1/2"
Seal Type: 2F - Standard Seal for Y-Bearings
Lubrication: Standard Lubrication
Special Treatment: No Special Treatment
Weight: 0.734 kg approx.

Dimensions:
Inner Diameter: 38.1 mm / 1.5"
Outer Diameter: 80 mm / 3.1496"
Width: 56.3 mm / 2.2165"

Suffix Description:
24: 1-1/2" bore size

Cross Reference / Interchange:
G1108-KRR-B
G1108-KRR-B-AS2/V
YEL208-108-2F

Description:
This listing is for one FYH NA208-24 insert ball bearing.

The NA208-24 is a bearing insert designed for use in compatible bearing housings and mounted bearing units. It features a 1-1/2" bore size, standard lubrication, and 2F standard seals for Y-bearing style applications.

Insert ball bearings are commonly used in pillow block units, flange units, take-up units, agricultural equipment, conveyors, fans, shafts, material handling systems, and general industrial machinery.

Main Features:

·         Genuine FYH NA208-24 insert bearing

·         1-1/2" bore size

·         Bearing insert for housings

·         Standard 2F seal design

·         Standard lubrication

·         38.1 mm bore size

·         80 mm outside diameter

·         56.3 mm width

·         Cross references G1108-KRR-B and YEL208-108-2F

·         Suitable for mounted bearing units and housing applications

·         Suitable for agricultural, conveyor, and industrial machinery applications

Please verify all dimensions, part number, bore size, seal type, housing compatibility, and application requirements before purchasing to make sure this item fits your application.







 PACKAGE INCLUDES: ONE (1) FYH Bearing NA208-24
