FAG UCF206-18-J7 — 4-Bolt Square Flanged Housing Unit (Cast Iron), Insert Bearing Included

Specifications

• Brand: FAG (Schaeffler)
• Item Number / MPN: UCF206-18-J7
• Manufacturer Part Number: 0812149360000 (also shown as 081214936-0000)
• EAN: 4047643251341
• Category: Housing and Bearing (assembly) / Flanged housing unit (UCF)

Also Known As (Cross References)

• FYJ 1.1/8 TF
• UC206-18 + F206-J7
• YAR206-102-2F + FYJ506

Dimensions & Weight

• Bore / Inner Diameter (d): 28.58 mm (1.125 in / 1-1/8")
• Flange / Housing Width (L): 108 mm
• Outer Dimension (housing): 108 mm (square flange)
• Overall Width (B): 40.2 mm (1.5827 in)
• Weight: 1.18 kg

Product Characteristics

• Unit Type: Square 4-bolt flanged housing unit
• Number of Holes: 4
• Housing Material: Cast iron
• Bearing Material: Standard bearing steel
• Sealing: Double seal / 2F standard seal for Y-bearings
• Fixing / Locking: Threaded pins (set screws / grub screws)
• Lubrication: Standard lubrication
• Temperature Range: -20°C to +120°C
• Version: Standard version

Load Ratings

• Dynamic Load Rating (Cr): 20,700 N
• Static Load Rating (C0r): 11,300 N

Suffix Meaning

• -18: 1-1/8" bore
• J7: Standard suffix with improved fit in the housing

Listing-Ready Copy (Paste-Friendly)

FAG UCF206-18-J7 is a complete 4-bolt square flanged housing unit (UCF type) with insert bearing installed, ready to mount. Features a cast iron housing, double sealing (2F), and set-screw locking (threaded pins) on a 1-1/8" bore (28.58 mm) shaft. Designed for reliable operation and easy installation in general industrial and agricultural applications. Operating temperature range -20°C to +120°C.
