Item Specifics:
Brand: FAG
Model / Item Number: 33009-XL
Also Known As: 33009
Manufacturer Part Number: 0926467350000
EAN: 4054372279461
Category: Tapered Roller Bearing Single Row
Bearing Type: Single Row Tapered Roller Bearing
Design: Separable Cup and Cone Assembly
Suffix: XL - X-Life
Precision: Standard Precision
Standard: Main Dimensions to DIN ISO 355 / DIN 720
ECLASS Number: 23-05-09-10
Quantity Available: 72 pcs
Weight: 0.432 kg approx.

Dimensions:
Inner Diameter: 45 mm / 1.7717"
Outer Diameter: 75 mm / 2.9528"
Width: 24 mm / 0.9449"
Inner Ring Width: 24 mm
Total Width: 24 mm

Load & Speed Ratings:
Radial Dynamic Load Rating Cr: 85,000 N
Radial Static Load Rating C0r: 104,000 N
Limiting Speed: 11,300 rpm
Thermal Speed Rating: 5,900 rpm

Suffix Description:
XL: X-Life design for improved performance, higher load capacity, and longer service life

Description:
This listing is for one FAG 33009-XL single-row tapered roller bearing.

The 33009-XL is a tapered roller bearing designed to support combined loads, including high radial loads and axial loads in one direction. The bearing uses tapered rollers between the inner and outer rings, with conical raceways that provide strong load-carrying capability.

This bearing is a separable design consisting of a cone assembly and a cup. The cone includes the inner ring, cage, and roller set, while the cup is the outer ring. This construction makes installation and disassembly easier in many industrial and mechanical applications.

The XL suffix indicates FAG X-Life design. X-Life bearings are manufactured with optimized internal geometry, improved contact surfaces, and high-quality rolling elements to provide higher load capacity, reduced heat generation, higher operating speeds, and longer service life compared with standard bearing designs.

Single-row tapered roller bearings must generally be mounted in mirror-image arrangement with a second tapered roller bearing. They may also be used in paired bearing arrangements such as X, O, or tandem configurations depending on the application.

Main Features:

·         Genuine FAG 33009-XL bearing

·         Single-row tapered roller bearing

·         X-Life performance design

·         Separable cup and cone assembly

·         Supports high radial loads

·         Supports axial loads in one direction

·         45 mm bore size

·         75 mm outside diameter

·         24 mm width

·         Standard precision

·         Main dimensions to DIN ISO 355 / DIN 720

·         Radial dynamic load rating: 85,000 N

·         Radial static load rating: 104,000 N

Please verify all dimensions, part number, load ratings, and specifications before purchasing to make sure this item fits your application.

   PACKAGE INCLUDES: ONE (1) FAG Bearing 33009 XL
