BRAND: PEER

ID: 607 2RS C3

DESCRIPTION:

• Also known as607 2RS C3
  607-2RS1/C3
  607-2RSR-C3
  PER.607-2RSUC3
• Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

• Inner (d) MM7
• Outer (D) MM19
• Width (B) MM6
• Inner (d) Inch0.2756
• Outer (D) Inch0.748
• Width (B) Inch0.2362
• Weight (kg)0.007

Product Properties

• Bore C - Cylindrical Bore
• Seal2RS - Rubber Seal on Two Sides
• Cage Type S - Steel or Standard Cage
• External Modification No External Modification
• Radial Internal PlayC3 Internal Play (Higher than Cn)
• Precision Standard Precision
• Lubrication Standard Lubrication
• Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
• Special Treatment No Special Treatment

Suffix description

Product description

The 607 2RSU C3 Peer is a miniature ball bearing. This is a very small single-row deep groove ball bearing. The design consists of an inner and an outer ring, with a ball and cage assembly in between. Thanks to their simple construction, these bearings require little maintenance. With their compact dimensions, miniature bearings are suitable for applications where space is limited.

Additionally, miniature ball bearings boast significant radial load-bearing capacity. The cage of the 607 2RSU C3 Peer ensures that the balls do not touch each other and move in a controlled manner. This generates less heat and allows for high speeds to be reached. Miniature ball bearings are therefore widely used in situations where very high rotational rates are required.

PACKAGE INCLUDES: ONE (1) PEER 607 2RS C3
